▶ Features:
Remote Communication Function(Optional)
Product can be configured with remote communication function,only need to connect with SIM card module,that can be controlled by phone's internet remotely.
Input Power | Rated Voltage/frequency | Three-phase 380V/480V;50Hz/60Hz |
Allowable Voltage range | +10%~-15% | |
Allowable Frequency Fluctuation | ± 5% | |
Control Features | Control Mode | PWM Vector Control |
Speed Adjustment Range | 0.01~500Hz | |
Speed Stabilization Precision | ± 0.1% | |
Acceleration/Deceleration time | 0.05~3000Hz/s | |
Torque Control | 200% Rated torque output;Torque precision ±5% | |
Position Control Precision | ±1 Pulse | |
Overload Capacity | Twice Overload | |
I/Os | Digital Input | 10 points , NPN or PNP(Optional) |
Digital Output | 6 points , NPN | |
Relay Output | 2pcs ,DC30V/1A Or AC250V/1A | |
Analog Input | 2 inputs, A0:±10V; A1: 0~±10V Or 4~20mA | |
External Pulse Input | 1 type ,ABZ phase pulse ,Pulse+Direction Or | |
Motor Encoder Input | 1 type,RS422 TTL , Rotatry Connector(Optional) | |
Motor Encoder Output | 1 pcs,RS42TTL ,Output Frequency Range: | |
Protection Function | Over-Voltage Protection,Low-Voltage Protection,Over-Current Protection,Over-Heat | |
Ambient Temperature | -10℃ ~ +45℃ | |
Humidity | 5~90%, not allow condensing | |
Altitude | 0~3000Meters,derated above 1000m, the | |
Vibration | Under 20Hz:1G; 20~50Hz: 0.2G | |
