Number of control axes | 3 Axis |
Minimum programming | 0.001mm |
| Display | 8.4 inch color screen |
| interface | USB+RS232 Communction Port |
Maximum programming | ± 99999.999mm |
Top speed | 30m / min |
Feed speed | 0.001-15m / min |
Spindle functions | Gear, dual analog control, rigid tapping |
Pre-reading function | Short line preprocessing 10,000 lines |
| Function | ATC+PLC and macro function |
| Encoder lines | Any setting |
| User macro program | Yes |
| Our Services | 12 Months warranty；Provide professional CNC solutions； |
| Compensation function | Knife compensation, between compensation, screw compensation, radius compensation |
| Security function | Emergency stop, hardware travel limit, various stored travel checks, axis interlock, data backup and recovery |
| Compensation function | 1) Pitch error compensation: 360 compensation points for each of X, Z, and Y axes, each point compensation amount ± 0.007 x compensation magnification 2) Tool compensation execution mode: moving tool/coordinate offset (can be set by parameters) 3) Tool compensation: 64 sets of tool length compensation 4) Tool nose radius compensation 5) Backlash compensation: (X, Z, Y axis) 0 mm~65535mm |
FAQ
1. Can I trust you?
A: Sure, we're Alibaba verified supplier & Alibaba Trade Assurance Suppier.
2. How can we guarantee quality?
A: Always finishing a pre full testing by our professional engineers; Always final 100% Inspection before shipment.
If you have another question, pls feel free to contact us as below.
